The test socket can be fully customized according to customer needs
●BGA/LGA Pitch:0.3 ~1.27mm
●DFN/QFN Pitch :0.4/0.5mm
●QFP Pitch:0.35/0.4/0.5mm
Vertical Probe Card
●The test pin position can be up to ±10μm
●Smaller needle marks are left on the DUT
●Two types of probes: flat needle and point needle
●Fine pitch application for min pitch 90um
●Single pin replac……
WLCSP Probe Head
●The test pin position can be up to ±10μm
●Smaller needle marks are left on the DUT
●Two types of probes: flat needle and point needle
●Fine pitch application for min pitch 90um
●Single pin replac……
Changeover Kit
●ADV:M6242,M6243,M6541,M6542
●TW:TW350H,TW350HT
●MR:M500HT
Applies to IC specifications
●DDR3/DDR4/DDR5
●LPDDR3/LPDDR4/LPDDR5
●HBM……
Average monthly production capacity
●15~20 sets
Change over Kit
ENMICRO has the ability to independently design
simulate, and calculate tolerance chains to
form a closed loop to achieve contact reliability
