Rubber

PKG	Pitch (mm)	Thickness (mm)	Contact force @ Recommended Travel	Inductance (@1GHz)	Capacitance (@1GHz)	CRES AVR (mOhm)	Max.CCC	Band Width (GSG,-1dB@GHz)
BGA	0.3	0.45	8g @ 0.14 mm	0.09nH	0.06pF	80	1.5A	100 GHz
	0.35	0.45	10g @ 0.14 mm	0.10nH	0.09pF	80	1.5A	100 GHz
	0.4	0.55	12g @ 0.16 mm	0.12nH	0.08pF	75	2.0A	96 GHz
	0.5	0.75	15g @ 0.16 mm	0.17nH	0.11pF	65	2.5A	108 GHz
	0.65/0.7	0.8	20g @ 0.16 mm	0.16nH	0.20pF	65	3.0A	80 GHz
	0.8	0.9	25g @ 0.16 mm	0.19nH	0.23pF	60	4.5A	83 GHz
	1.0	1.0	28g @ 0.2 mm	0.19nH	0.25pF	60	5.0A	96 GHz
